| Processor | |
| Supported CPU | Intel Socket LGA1700 For Intel Core 14th & 13th Gen Processors, Intel Core 12th Gen, Pentium Gold And Celeron Processors* Supports Intel Turbo Boost Technology 2.0 And Intel Turbo Boost Max Technology 3.0** |
| Mainboard | |
| Chipset | Intel Z790 Chipset |
| Memory | |
| Memory | 4 X DIMM Slots, Max. 192GB, DDR5 8000+ (OC)/7800(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 Non-ECC, Un-Buffered Memory* Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) Memory Module ASUS Enhanced Memory Profile II (AEMP II) Supports DIMM Flex |
| Graphics | |
| Graphics | 1 X HDMI Port 2 X Intel Thunderbolt 4 Ports (USB Type-C) Support DisplayPort And Thunderbolt Video Outputs ** Supports 4K@60Hz As Specified In HDMI 2.1 |
| Networking & Connectivity | |
| LAN | 1 X Realtek 5Gb Ethernet ASUS LANGuard |
| Bluetooth | Bluetooth V5.4 |
| Ports | |
| Slots | Intel Core Processors (14th & 13th & 12th Gen)* 2 X PCIe 5.0 X16 Slots (Supports X16 Or X8/X8 Modes)** Intel Z790 Chipset 1 X PCIe 4.0 X4 Slot |
| Internal I/O Ports | Fan And Cooling Related 1 X 4-Pin CPU Fan Header 1 X 4-Pin CPU OPT Fan Header 1 X 4-Pin AIO Pump Header 4 X 4-Pin Chassis Fan Headers 1 X W_PUMP+ Header 1 X 2-Pin Water In Header 1 X 2-Pin Water Out Header 1 X 3-Pin Water Flow Header Power Related 1 X 24-Pin Main Power Connector 2 X 8-Pin +12V Power Connectors 1 X 8-Pin PCIe Power Connector Storage Related 5 X M.2 Slots (Key M) 4 X SATA 6Gb/S Ports USB 1 X USB 20Gbps Connector (Supports USB Type-C ) 2 X USB 5Gbps Headers Support 4 Additional USB 5Gbps Ports 2 X USB 2.0 Headers Support 4 Additional USB 2.0 Ports Miscellaneous 3 X Addressable Gen 2 Headers 1 X Alteration PCIe Mode Switch 1 X Aura RGB Header 1 X CPU Over Voltage Jumper 1 X FlexKey Button 1 X Front Panel Audio Header (F_AUDIO) 1 X ReTry Button 1 X Start Button 1 X 10-1 Pin System Panel Header 1 X Thermal Sensor Header |
| External I/O Ports | 2 X Thunderbolt 4 USB Type-C Ports 6 X USB 10Gbps Ports (5 X Type-A + 1 X USB Type-C) 4 X USB 5Gbps Ports (4 X Type-A) 1 X HDMI Port 1 X Wi-Fi Module 1 X Realtek 5Gb Ethernet Port 5 X Gold-Plated Audio Jacks 1 X Optical S/PDIF Out Port 1 X BIOS FlashBack Button 1 X Clear CMOS Button |
| USB | Rear USB (Total 12 Ports) 2 X Thunderbolt 4 Ports (2 X USB Type-C) 6 X USB 10Gbps Ports (5 X Type-A + 1 X USB Type-C) 4 X USB 5Gbps Ports (4 X Type-A) Front USB (Total 9 Ports) 1 X USB 20Gbps Connector (Supports USB Type-C With Up To 60W PD/QC4+)** 2 X USB 5Gbps Headers Support 4 Additional USB 5Gbps Ports 2 X USB 2.0 Headers Support 4 Additional USB 2.0 Ports * USB Type-C Power Delivery Output: Max. 5V/3A ** USB Type-C Power Delivery Output: 5/9/15/20V Max. 3A, PPS:3.3–21V Max. 3A |
| Technical Info | |
| BIOS | WOL By PME, PXE |
| Operating System | Windows 11, Windows 10 64-Bit |
| Special Features | |
| Special Features | Extreme OC Kit – FlexKey Button – ReTry Button – Start Button Extreme Engine Digi+ – 10K Black Metallic Capacitors – MicroFine Alloy Choke ASUS Q-Design – M.2 Q-Latch – PCIe Slot Q-Release – Q-Antenna – Q-Code – Q-Connector – Q-DIMM – Q-LED (CPU [Red], DRAM [Yellow], VGA [White], Boot Device [Yellow Green]) – Q-Slot ASUS Thermal Solution – HybridChill VRM Block – M.2 Heatsink Backplate – M.2 Heatsink – Metal Backplate – VRM Heatsink Design ASUS EZ DIY – BIOS FlashBack Button – Clear CMOS Button – CPU Socket Lever Protector – ProCool II – Pre-Mounted I/O Shield – SafeSlot – SafeDIMM Aura Sync – Aura RGB Header – Addressable Gen 2 Headers OLED 2″ Front Panel USB 20Gbps With Quick Charge 4+ Support – Support: Up To 60W Fast Charging And USB Wattage Watcher* – Output: 5/9/15/20V Max. 3A, PPS:3.3–21V Max. 3A – Compatible With PD3.0 And PPS * To Support 60W, Please Install The Power Cable To The 6-Pin PCIe Power Connector Or Else Only 27W Will Be Supported. |
| Software Features | ROG Exclusive Software – ROG CPU-Z – DTS Sound Unbound – Internet Security (1-Year Full Version) ASUS Exclusive Software Armoury Crate – AIDA64 Extreme (1 Year Full Version) – Aura Creator – Aura Sync – Fan Xpert 4 (With AI Cooling II) – GameFirst – Power Saving – Sonic Studio – Two-Way AI Noise Cancelation – OLED Display AI Suite 3 – Easy Optimization With AI Overclocking – TPU – DIGI+ Power Control – Turbo App – PC Cleaner MyASUS USB Wattage Watcher Intel Unison Adobe Creative Cloud (Free Trial) WinRAR (40 Days Free Trial) UEFI BIOS AI Overclocking Guide ASUS EZ DIY – ASUS CrashFree BIOS 3 – ASUS EZ Flash 3 – ASUS UEFI BIOS EZ Mode – ASUS MyHotkey MemTest86 |
| Physical Specification | |
| Form Factor | ATX Form Factor |
| Dimension | 12 Inch X 9.6 Inch ( 30.5 Cm X 24.4 Cm ) |
| Others | |
| Included In The Box | Cables 1 X ARGB RGB Extension Cable 2 X ROG Weave SATA 6G Cables 2 X SATA 6Gb/S Cables Additional Cooling Kit 1 X DDR5 Fan Holder 1 X Thermal Pad For M.2 Miscellaneous 1 X ASUS WiFi Q-Antenna 1 X Q-Connector 3 X M.2 Backplate Q-Latch Packages 1 X ROG Key Chain 1 X ROG Stickers 1 X ROG VIP Card 1 X M.2 Rubber Package 3 X M.2 Backplate Rubber Packages Installation Media 1 X USB Drive With Utilities And Drivers Documentation 1 X Quick Start Guide |
